| GD-dp系列單螺母滾珠絲桿 |
|
|
|
|
單位：mm
|
規格型號
|
外徑d
|
導程I
|
鋼珠徑φ
|
軸向鋼性
|
基本額定荷重
|
螺母尺寸
|
安裝孔
|
注油孔
|
|
Kgf/μm
|
動額定負荷Ca
|
靜額定負荷Coa
|
外徑D
|
法蘭徑F
|
螺母長度L
|
法蘭厚度T
|
安裝孔距PCD
|
X
|
Y
|
Z
|
Q
|
|
GD1605-3
|
16
|
5
|
3.175
|
16
|
640
|
1340
|
30
|
49
|
50
|
10
|
39
|
4.5
|
8
|
4.5
|
M6×1
|
|
GD1610-2.7
|
16
|
10
|
3.175
|
15
|
780
|
1790
|
30
|
58
|
44
|
10
|
39
|
4.5
|
8.5
|
5
|
M6×1
|
|
GD2005-3
|
20
|
5
|
3.175
|
25
|
901
|
1934
|
34
|
57
|
51
|
11
|
45
|
5.5
|
9.5
|
5.5
|
M6×1
|
|
GD2505-4
|
25
|
5
|
3.175
|
35
|
1280
|
3110
|
40
|
63
|
51
|
11
|
51
|
5.5
|
9.5
|
5
|
M6×1
|
|
GD2510-4
|
25
|
10
|
4.7625
|
33
|
1944
|
3877
|
46
|
72
|
85
|
12
|
58
|
6.5
|
11
|
6.5
|
M6×1
|
|
GD3205-4
|
32
|
5
|
3.175
|
40
|
1421
|
4067
|
46
|
72
|
52
|
12
|
58
|
6.5
|
11
|
6
|
M8×1
|
|
GD3210-4
|
32
|
10
|
6.350
|
40
|
3288
|
6955
|
54
|
88
|
90
|
15
|
70
|
9
|
14
|
8.5
|
M8×1
|
|
GD4005-4
|
40
|
5
|
3.175
|
49
|
1578
|
5223
|
56
|
90
|
55
|
15
|
72
|
9
|
14
|
8.5
|
M8×1
|
|
GD4010-4
|
40
|
10
|
6.350
|
50
|
3871
|
9425
|
62
|
104
|
93
|
18
|
82
|
11
|
17.5
|
11
|
M8×1
|
|
GD5010-4
|
50
|
10
|
6.350
|
65
|
4405
|
12375
|
72
|
114
|
93
|
18
|
92
|
11
|
17.5
|
11
|
M8×1
|
|
GD6310-4
|
63
|
10
|
6.350
|
103
|
5026
|
16455
|
90
|
131
|
98
|
22
|
108
|
14
|
20
|
13
|
M8×1
|
|
GD8020-6
|
80
|
20
|
7.144
|
249
|
12525
|
45075
|
125
|
200
|
170
|
30
|
152
|
18
|
27
|
16
|
M10×1
|
|
|
